| Diameter | Buttons | Flushing Hole | Weight | Model No. | |||
[mm] | [in] | Gauge [No.] × [mm] | Front [No.] × [mm] | Side [No.] | Front [No.] | [kg] | |
| 89 | 3 1/2" | 6 × 16 | 4 × 13 | - | 2 | 4.5 | T51-8910ZCP |
| 102 | 4" | 6 × 16 | 4 × 14 | - | 2 | 5.8 | T51-10210ZCP |
| 89 | 3 1/2" | 7 × 13 | 5 × 12 | 1 | 3 | 2.7 | T51-8912ZCP |
| 89 | 3 1/2" | 9 × 12 | 6 × 12 | 1 | 3 | 4.9 | T51-8915ZCP |
| 89 | 3 1/2" | 8 × 13 | 5 × 12 | 2 | 2 | 4.9 | T51-8913ZCP |
| 89 | 3 1/2" | 8 × 13 | 6 × 12 | - | 2 | 4.9 | T51-8914ZCP |
| 102 | 4" | 8 × 14 | 7 × 12 | 2 | 2 | 5.8 | T51-10215ZCP |
| 102 | 4" | 8 × 16 | 6 × 13 | 2 | 2 | 6 | T51-10214ZCP |
| 115 | 4 1/2" | 9 × 14 | 7 × 13 | 1 | 3 | 6.8 | T51-11516ZCP |
| 115 | 4 1/2" | 8 × 16 | 7 × 13 | 2 | 2 | 6.8 | T51-11515ZCP |
| 127 | 5" | 8 × 16 | 9 × 12 | - | 2 | 7.5 | T51-12717ZCP |
| 89 | 3 1/2" | 9 × 11 | 6 × 10 | - | 2 | 4.6 | T51-8915ZCP1 |
| 102 | 4" | 9 × 12 | 7 × 12 | - | 3 | 5.9 | T51-10216ZCP |
| 102 | 4" | 9 × 12 | 6 × 12 | - | 3 | 5.8 | T51-10215ZCP1 |
| 115 | 4 1/2" | 9 × 14 | 7 × 13 | 1 | 3 | 6.6 | T51-11516ZCP1 |
| 127 | 5" | 9 × 14 | 7 × 13 | - | 3 | 7.5 | T51-12716ZCP |
| 127 | 5" | 9 × 14 | 8 × 14 | - | 3 | 8.4 | T51-12717ZCP1 |
| 152 | 6" | 9 × 16 | 11 × 14 | - | 3 | 11.1 | T51-15220ZCP |
| 89 | 3 1/2" | 8 × 12 | 4 × 11, 1 × 11 | - | 4 | 4.6 | T51-8913ZCA |
| 89 | 3 1/2" | 8 × 12 | 4 × 12, 2 × 10 | 1 | 4 | 4.5 | T51-8914ZCA |
| 102 | 4" | 8 × 12 | 4 × 12, 4 × 11 | - | 4 | 4.7 | T51-10216ZCA |
| 115 | 4 1/2" | 8 × 14 | 4 × 13, 2 × 13 | 1 | 4 | 6.8 | T51-11514ZCA |
| 127 | 5" | 8 × 14 | 4 × 14, 4 × 13 | - | 4 | 7.5 | T51-12716ZCA |
| 165 | 6 1/2" | 9 × 16 | 9 × 14, 4 × 14 | - | 3 | 14.4 | T51-16522ZCA |
| 178 | 7" | 9 × 16 | 9 × 16, 4 × 14 | - | 3 | 15.1 | T51-17822ZCA |
| 89 | 3 1/2" | 8 × 12 | 4 × 12 | - | 4 | 3.6 | T51-8912ZCH |
| 102 | 4" | 9 × 13 | 4 × 13 | - | 4 | 4.1 | T51-10213ZCH |
| 115 | 4 1/2" | 9 × 13 | 4 × 13 | - | 4 | 6.3 | T51-11513ZCH |
| 127 | 5" | 8 × 16 | 6 × 14 | - | 4 | 7.4 | T51-12714ZCH |
| 152 | 6" | 8 × 18 | 6 × 16 | - | 4 | 12 | T51-15214ZCH |
